Bose F1 Subwoofer Travel Bag

Niles Audio / Video Remote Control Anywhere Kit for Home Theater

The Niles RCA-HT2 Remote Control Anywhere! Kit enables you to operate your remote controlled audio/video equipment from virtually any location. Now you can place your audio/video (A/V) components out of sight (behind cabinet doors, in the rear of a room, or in a different room) and still conveniently control your system.

What’s in the box:

• Connection Hub
• Surfance Mount Microsensor
• 12VDC Power Supply
• Microflasher
• CAT-5 Sensor Cable (50′) (15.24 meters)

Features and Benefits — Remote Control Anywhere! Kit

Complete System
Everything needed to assemble a complete IR extender system is included in one box:
One Infrared Microsensor
Receives/initiates the IR commands and routes them to the Main System Unit
One Main System Unit
Amplifies and distributes the commands to the infrared flashers
IR Microflasher (Five)
Transmit the IR commands to the audio/video components

Features and Benefits — IR MicroSensor

High-Fidelity Wideband Design
Ensures compatibility with virtually and brand of equipment, even those using faster, more difficult to reproduce IR codes
Patent Pending Universal Noise Suppression Design
Enables operation in virtually any IR environment near plasma and LCD displays, compact fluorescent lights, and direct sunlight.
Extended IR receiving Range
Enjoy the convenience of 20′ to 35′ of remote control range (6.1 meters to 10.6 meters)
Printed Circuit Board
Our printed circuit board uses surface mount technology (SMT) to ensure reliability
Small Size
Discretely blends into environment
Extra Long Cable
10′ of connecting cable included

Features and Benefits — Main System Unit

Universal System
Compatible with virtually all brands of audio/video equipment and remote controls
Versatile Connections
Accommodates one IR MicroSensor with removable screwless connector plus four IR flashers via 3.5 mm jacks
System Feedback LED
Confirms proper operations
3-30V AC/DC Status Input
Provides system status to connected sensors and keypads
Expandable
An IRH610 IR Expansion Hub can be used to provide additional inputs
Integrated Mounting Wings
Both Horizontal and vertical installation is supported
Power Supply
UL listed regulated power supply with universal voltage capability
12VDC Output
This is useful for triggering external devise and system automation
2x Variable
Flasher out (4 +5) allows for use of high output flasher (sold separately)

Features and Benefits — MicroFlasher

Miniature and Discrete
Each MicroFlasher mounts directly to the IR remote sensor window of your audio/video equipment while maintaining a clean appearance
Visible Feedback
Provides feedback of flasher operation via a red LED in the flasher housing
Transparent to IR commands
Even though the MicroFlasher covers the IR remote sensor window, you can still directly operate your equipment using a remote control
Easy Installation
A strip of self-adhesive tape provides secure mounting
Connecting Wire
A 10′ connecting wire (3 m) is fitted with a 3.5 mono mini-plug to provide a secure connection to the MSU
